|WARNING: This page deals with subject matter which may disturb some. Please be aware that this page deals with medical conditions, and does include visual aids.|
The discussion which follows focuses on the search for evidence of arterial and venous insufficiency as well as edema. These are the most common serious ailments which affect the lower extremities and therefore merit the greatest attention. Joint and neurologic examinations are covered elsewhere.
The Femoral Region
As with examination of any other area of the body, exposure is key. Socks, stockings, pants and skirts should all be removed.
- Begin by simply looking at the area in question, which is on either side of the crease separating the leg from the groin region. Make note of any discrete swellings, which might represent adenopathy or a femoral hernia.
- Palpate the area, feeling carefully for the femoral pulses as well as for inguinal/femoral adenopathy (nodes which surround the femoral artery and vein…. up to one cm in size are considered non-pathologic). If you feel any lymph nodes, note if they are firm or soft, fixed in position or freely mobile (fixed, firm nodes are more worrisome for pathologic states).
University of Washington, Femoral region anatomy
- The femoral pulse should be easily identifiable, located along the crease midway between the pubic bone and the anterior iliac crest. Use the tips of your 2nd, 3rd and 4th fingers. If there is a lot of subcutaneous fat, you will need to push firmly.
- A femoral hernia, if present, is located on the anterior thigh, medial to the femoral artery. As it can be transient (i.e. the patient reports its presence yet you find nothing on examination), investigation should include observation as well as palpation while the patient performs a valsalva maneuver, which may make a hernia more prominent.
The Popliteal Region
- Move down to the level of the knee allowing it to remain slightly bent.
- Place your hands around the knee and push the tips of your fingers into the popliteal fossa in an effort to feel the popliteal pulse. Note whether it feels simply pulsatile (normal) or enlarged and aneurysmal (uncommon). This artery is covered by a lot of tissue and can be difficult to identify, so you may need to push pretty hard. Even then, it may not be palpable, which is not clinically important if you can still identify the more distal pulses (see below).
Below The Knee
Now, turn your attention to the lower leg (i.e. from the knee to the foot). First, examine with your eyes, paying attention to:
- Color: Venous insufficiency is characterized by a dark bluish/purple discoloration. Over time, long standing stasis of blood leads to the deposition of hemosiderin, giving the skin a dark, speckled appearance. If the leg is placed in a dependent position, the bluish/purple discoloration may darken dramatically, further suggestive of venous insufficiency. This occurs as a result of gravity working against an already ineffective blood return system. Patients with severe arterial insufficiency, on the other hand, may have relatively pale skin as a result of under perfusion. When their legs are placed in a dependent position, gravity enhances arterial inflow and the skin may become more red as maximally dilated arterioles attempt to bring blood to otherwise starved tissues. In cases of severe ischemia, the affected areas (usually involving the most distal aspect of the foot), can appear whitish or mottled, giving the leg a marbleized appearance. Dead tissue turns black (a.k.a. gangrene). Cellulitis (infection in the skin) will cause the skin to appear bright red. These changes can be difficult to detect in people of color.
|Acute Arterial Insufficiency:|
Note Mottled Appearance of Skin
|Chronic Arterial Insufficiency with Ulcers||Gangrene of Toes ||Venous Insufficiency||Cellulitis|
- Obvious swelling of the leg: If present, is it symmetric? To what level does the swelling exist
(i.e. ankle, calf, knee etc.)?
Assymetric Leg, Swelling secondary to Deep Venous Thrombosis in Right Leg.
- Nail growth: Nail thickening and deformity often occurs with arterial insufficicency; also with fungal
- Skin: Any obvious growths? Shiny, hairless appearance (seen with arterial insufficiency)?
Dilated or varicose superficial veins? Ulceration of the skin can occur in the setting of either
venous or arterial disease.
Venous Stasis Ulcer
- The bottom of the foot and between the toes: These are common “problem areas,” particularly
in patients with diabetes who are predisposed as a result of sensory impairment, arterial
insufficiency, or both.
Neuropathic Ulcer in Patient with Diabetic Neuropathy
- Probing the depth of an ulcer: Ulcers can extend rather deeply. This can
be explored with the use of a Q-tip. If the bone is visible or can be reached
with the Q-tip, the infection is assumed to involve the underlying structure.
This is referred to as clinical osteomyelitis. It’s worth noting that if the
ulcer developes in a patient with neuropathy (as is the case here), then the
act of probing does not cause pain because the area is insensate.
Clinical Osteomyelitis: Deep ulcer which permits passage of Q-tip to underlying level of bone.
Feel the skin, noting in particular
- Temperature: Arterial insufficiency will often cause the skin to feel cool. Infection, on the
other hand, causes hyperemia and relative warmth. The back of your hand may be the most
sensitive surface for detecting subtle temperature difference. Compare one leg to the other. It’s
also OK to use your own skin (e.g. face) as a reference point. Note that in cases where arterial
insufficiency and infection occur simultaneously (which is quite common), impaired inflow of
blood may generate less warmth (and also less redness) then might otherwise be expected.
- Edema: Fluid frequently collects in the feet and ankles due to the effects of gravity. This is related to some perturbation in the Startling forces. Thinking in broad strokes, it’s usually the result of:
Low oncotic pressure: Either failure to synthesize albumin (as with malnutrition or liver
disease) or increased loss of albumin (via the kidney or local leakage due to altered
Increased hydrostatic pressure: Transmitted back from the level of the heart (right heart failure), liver (portal hypertension), local venous insufficiency (e.g. venous valvular incomepetence with impaired flow of blood back to the heart from the legs), lymphatic obstruction (e.g. retroperitoneal adenopathy secondary to malignancy), or obesity (which may impair both venous and lymphatic drainage).
Realize that all “circulation” problems are not the same. Disorders of blood inflow (arterial) and
outflow (venous) have different associated signs and symptoms based on their varying
pathophysiology (see above). Edema is commonly associated with venous
insufficiency, a blood return problem. This disorder tends to get worse when the legs are allowed
to dangle for prolonged periods below the level of the heart (e.g. towards the end of the day if the patient has
been standinag for long periods of time). The fluid builds up preferentially in the most distal aspects of the leg and progress up towards the knee as the process worsens. Arterial insufficiency, on the other
hand, rarely causes edema, which makes perfect sense as the problem lies in the delivery of blood to
the extremity, not the return from it. On occasion, the conditions may coexist.
It may be difficult to detect small amounts of fluid. Look around the malleoli, as fluid
will cause a loss of the normally distinct appearing edges of the bone. Similarly, fluid will
tend to “fill in” the spaces between the extensor tendons on the top of the foot, causing them to
appear less defined. If you’re not sure whether fluid is present, push on the area for several
seconds, release, and then gently rub your finger over that same spot, feeling for the presence of a
“divot,” referred to as pitting. Much is said about pitting edema being associated with some
disease states and non-pitting with others; however, the actual importance of this distinction
is probably over stated. Also note the proximal extent of the edema and if it is present to the
same degree in both legs. Edema may either be diffuse, involving all of the surrounding tissue
symmetrically, as is frequently the case in disorders of low oncotic or elevated hydrostatic
pressure. If, however, there is a local inflammatory process, as might occur with cellulitis, the area
of edema can be quite focal. There is a very subjective scale for rating edema which ranges from
“trace at the ankles” to “4+ to the level of the knees.” After examining many patients, you’ll
develop a sense of what is a lot and what is not.
|Edema of Right Foot.|
Note Loss of Distinct Edges of Malleolous and Extensor Tendons on Top of Foot
|Massive edema. |
Note: Remaining imprint of fingers.
|Lymphedema, Left Leg|
- Capillary Refill: Push on the tip of the great toe or the nail bed until blanching occurs. Then
release and note how long it takes for the red color to return, a reflection of blood inflow to the
distal aspect of the lower extremity. Longer then 2-3 seconds is considered abnormal
and consistent with arterial insufficiency. Refill may also be delayed in the setting of significant
hypovolemia, as decreased blood volume available for perfusion is shunted away from the
extremities to feed more vital organs.
- Skin that is discolored from venous insufficiency blanches when pushed and it generally takes
more then a few seconds for the bluish hue to return. Cellulitic areas, however, blanch and
then very rapidly return to their bright red coloration. This can be helpful as it will
occasionally be difficult to determine if infection and venous insufficiency are both present.
- Pain: Cellulitic skin, for example, is often tender when touched. Remember that certain disease
states (diabetes in particular) cause a peripheral neuropathy that predisposes these patients to the development of skin breakdown and subsequent infection precisely because they have abnormal sensation in their distal extremities. In these cases, then, infection may occur in the absence of pain.
Paronychia Great Toe Note: Swelling and redness along lateral edge of nail.
- Note the character of any swollen area: Does it feel full of edema fluid? Is there a suggestion
of a solid mass (uncommon)? Is there focal fluctuance, as would occur in an abscess?
The Distal Pulses
Pulses are assessed to identify the presence of arterial
vascular disease. In general, the less prominent the pulses, the greater the chance
that there is occlusive arterial disease. This is not a perfect correlation, however,
as pulses may be palpable even when significant disease is present (e.g. may be
affecting predominantly smaller, more distal blood vessels). A history of pain/cramps
with activity suggestive of arterial insufficiency is also of great importance.
The location of the blockage(s) will dictate the symptoms and findings. Aorto-iliac
disease, for example, will cause symptoms in the hips/buttocks and a loss of the
femoral pulse while disease affecting the more distal vessels will cause symptoms
in the calves and feet.
- The Dorsalis Pedis (DP) Artery: Located just lateral to the extensor tendon
of the big toe, which can be identified by asking the patient to flex their
toe while you provide resistance to this movement. Gently place the tips of
your 2nd, 3rd and 4th fingers adjacent to the tendon and try to feel the pulse.
If you can’t feel it, try moving your hand either proximally/distally or more
laterally and repeat. Common pitfalls include pushing too hard and/or mistaking
your own pulse for that of the patient. Palpating the patients radial artery
or your own carotid simultaneously with your free hand can help sort this
The pictures below demonstrate the location of the dorsalis pedis artery in relation to surrounding structures (surface anatomy on left, gross anatomy in the middle).
|Location of Dorsalis Pedis Artery||Palpating Dorsalis Pedis Artery|
of Washington, Dorsalis pedis artery anatomy
- The Posterior Tibial (PT) Artery: Located just behind the medial malleolous.
It can be palpated by scooping the patient’s heel in your hand and wrapping
your fingers around so that the tips come to rest on the appropriate area.
Alternatively, you can reach your fingers over the top of the medial malleolous
and approach the artery from this direction. In either case, you are attempting
to locate the artery using the tips of your fingers. Pitfalls mentioned with
the DP also apply here.
The pictures below demonstrate the location of the posterior tibial artery in relation to surrounding structures (surface anatomy on left, gross anatomy in the middle).
|Location of Posterior Tibial Artery||Palpating Posterior Tibial Artery|
of Washington, Posterior tibial artery anatomy
- If there is a lot of edema, you will have to push your way through the fluid-filled
tissue to get down to the level of the artery.
- If you are unable to palpate a pulse, find a doppler machine, which should
be present on any inpatient floor or ER, and use it to identify the location
of the artery. Mark the place with a pen and then go back and again try to
feel it with your fingers. In this way, you will be able to determine if the
vessel was not palpable on the basis of limited blood flow or if you are simply
having a “technical” problem.
Using Doppler Device to Identify Posterior Tibial Artery
- Pulses are rated on a scale ranging from 0 (not palpable) to 2+ (normal).
As with edema, this is very subjective and it will take you a while to develop
a sense of relative values. In the event that the pulse is not palpable, the
doppler signal generated is also rated, ranging again from 0 to 2+.
|Adapted, with permission from University of California, San Diego School of Medicine By Charlie Goldberg, M.D.|
